â� Optical Parts Disassemblies
5. POLARIZED GLASS-OUT REMOVAL
1. Remove four screw A and take the LCD Panel/Prism Ass�y upward from the Optical Unit. 2. Remove each screw B and take the glass off upward. LCD Panel/Prism Ass�y B
Note: 1. Do not replace the LCD panel separately otherwise
it can not obtain proper picture
A
A A
A
Note 2 Polarized Grass-Out
2. Should be replaced the glass as the film attached
side comes to the LCD panel side.
LCD Panel
Fig. 5
6. OPTICAL UNIT TOP REMOVAL
1. Remove eight screws to take the Optical Unit Top off upward.
Fig. 6
-17-
|
|
|
> |
|
