CHAPTER 3. REPAIR INSTRUCTION
4
1. Place the camera so that lens is set against the light source surface of the Brightness Box via the C-12 Filter. 2. Set the Brightness Box to EV12. 3. Click the �Check� button. 4. Check the Brightness level if it is within 0 ± 5. * If not, calibrate the Brightness Box until it becomes within 0 ± 5. 5. Click the �NEXT� button.
C-12 Filter
Brightness Box CAMERA BODY Power Source
Personal Computer
5
1. When the message on the right appears, Set the Brightness Box to EV15 and attach the ND-8 Filter while setting the C-12 Filter between the lens. 2. Click the �Check� button. 3. Check the Brightness level if it is within 0 ± 5. * If not, calibrate the Brightness Box until it becomes within 0 ± 5. 4. Click the �NEXT� button.
6
When the message on the right appears go to 7.
7
1. Attach the ND-4 Filters between the Lens and the Color Viewer. 2. Place the camera so that the lens is set against the center part of the Color Viewer. 3. Click the �ADJUST� button.
Color Viewer
ND-4 Filter CAMERA BODY Power Source Stand
Personal Computer
3-24
|
|
|
> |
|
