ASSEMBLY
When assembling the unit, check the following points. 1. Be sure to align the slide switch on the linear PCB with the switch knob.
Upper case
Back light
Switch knob
Linear PCB Slide switch
2. Be sure to align the slide switch on the key PCB with the switch knob.
Switch knob
Slide switch 3. Push hard the upper case with both hands.
� 20 �
|
|
 |
> |
|
|
