DISASSEMBLY
1. Unscrew two screws (S4) on the side. 5. Use a (�) screwdriver to remove the small hook.
screw (S4)
hook
2. Unscrew a screw (S4) on the bottom. screw (S4)
6. Remove the upper case.
3. Open battery cover.
7. It should look like this.
4. Release the hook on the side.
8. Remove the top case by lifting it up.
hook
� 16 �
|
|
 |
> |
|
|
