6. Remove the key PCB and two screws on the digital PCB. Screws
Key PCB
Digital PCB
7. Remove the two screws on the camera unit.
Screws
Camera unit
8. Unhook the slide switches of the camera unit, then remove the digital PCB and the camera unit.
Switch
9. Remove the three screws, then remove the back light. Note: Be sure not to lose the spacer.
Screws
Back light
Spacer for LED
