3) Detach your finger from SL button. 4) Remove the battery. 5) Pull in the crown. 6) Press second hand on the wheel shaft according to the procedure mentioned in �WATCH BASIC REPAIR MANUAL (RANK C AND D).
8-6. BATTERY REPLACEMENT
1) Open the back cover and see the display. When �CLOSE� appears on the display, close the back cover and wait for 2 minutes until �CLOSE� disappears. Then open the back cover again. (When you open the back cover just at the same time as the LSI does the sorting process, �CLOSE� appears on the display.) 2) Replace the battery with new one. 3) Perform AC operation according to the procedure 8-1. 4) Close the back cover. When �WAIT� appears on the display, wait 12 minutes at most. Watch can be used after �WAIT� disappears.
� 18 �
|
|
|
> |
|
