5. PARTS LIST : QW-1545
Note: 1. Prices and specifications are subject to change without prior notice. 2. Spare parts are classified as follows according to their importance in after-sales service. A Rank ............................... Very Important B Rank ............................... Important C Rank ............................... Less important 3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis. Batteries in Brister pack will be supplied from our Sales Department. 4. As for order/supply of spare parts, refer to the separate publication �GUIDEBOOK for spare parts supply�.
I t e m Code No. Parts name Specification Applicable Q R
7072 3561 Module 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 7001 2359 7240 9172 7101 0185 7020 0333 7020 5413 7100 7917 7110 0693 7103 0458 2895 2002 7103 2477 7103 3866 7103 7443 7101 5609 7103 7450 7020 5819 7230 0616 7010 4525 7236 0224 7231 0861 7233 1953 7231 1477 7234 1078 7234 1085 7231 1484 7211 0064 7211 9631 7233 1960 LCD P.C.B. with components Transistor Coil Coil Inverter IC Quartz oscillator Trimmer capacitor Tantalum capacitor Chip capacitor Chip capacitor Chip capacitor Diode Chip resistor EL Coil spring 1199-1 Interconnector 1545 Battery contact (-) 1199 Terminal plate 1288-2 Spacer 1545 Main plate 1545 Housing 1545-1 Housing 1545-2 Battery supporter 1405 Cushion 6 Cushion 506 Cushion 1545 Battery
QW-1545DF01 C1545-01P Q251268*1 2SD1149(TX) OL3.3X1.6DR-04 ELT3K104B MIP803000L DT-26SJ TSF-2L2-120-4.2 F950J106MRAAQ2 CM-2617YV304P15V GRM40-002F104P25PT CM21W5R472K25AT MA1010000L ERJ6GEYF364V EL-1545-A-02 Q437728B-1 Q455227-1 Q341452C-1 Q450360-1 Q455244-1 Q150449-1 Q150444-1 Q150445-1 Q352952-2 Q4914-1 Q49364-1 Q455246-1 CR 2016
DW-5600E QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01 QW-1545DF01
1 1 1 1 1 1 1 1 1 1 1 3 1 1 1 1 2 2 1 1 1 1 1 1 1 1 1 1 1
A A A B B B B B B B B B B B B B B C C C C C C C C C C C
*For the price, new parts and minimum quantity of the above parts, please refer to the Parts Price List P.P.L-510.
Notes:
Q � Used quantity R � Rank
-7-
|
|
|
> |
|
