CONTENTS
1. 2. 3. Page SPECIFICATIONS: QW-1700..................................................................... 1 OPERATION CHART: QW-1700 ................................................................ 2 DRAWINGS 3-1. BLOCK DIAGRAMS: QW-1700 .......................................................... 4 3-2. CHECKING TERMINALS AND COMPONENTS: QW-1700 .............. 5 3-3. ACCURACY SETTING SYSTEM ........................................................ 5 EXPLODED VIEW: QW-1700 ..................................................................... 6 PARTS LIST: QW-1700 .............................................................................. 7 EXPLODED VIEW: ANALOG BLOCK (C-1.2) OF QW-1700 .................... 8 PARTS LIST: ANALOG BLOCK (C-1.2) OF QW-1700 ............................. 9 PRECAUTIONS FOR REPAIR: QW-1700 8-1. AC (ALL CLEAR) AND REMOVING OF MODULE ........................... 10 8-2. BATTERY REPLACEMENT .............................................................. 10 8-3. ACCURACY CHECKING ................................................................... 10
4. 5. 6. 7. 8.
1. SPECIFICATIONS: QW-1700
Item Battery Battery life Current consumption Alarm system Accuracy Accuracy setting system Accuracy checking Accuracy setting Functions Detail CR927W (for watch), 626W (for EL) Approx. 3 years 1.31 µA maximum Piezo plate on Cover/Back ±20 sec./month Pattern cutting method (P1 ~ P5) See page 10 Unadjustable � Shock resistant (G-SHOCK) � Electro-luminescent backlight � "ANTIMAGNETIC" watch (ISO) � 1/100 sec. stopwatch Measuring capacity: 59�59.99� Measuring modes: Elapsed time, split time, 1st-2nd place times Memory capacity: 20 lap time records with lap number � Countdown alarm Input range: 1 sec. to 60 min. Unit: 1/10 sec. � Regular timekeeping Analog: 2 hands (Hour, minute) Digital: Hour, minutes, pm, day of the week, date, seconds � Auto-calendar (pre-programmed until the year 2039) � 3 daily alarms � Hourly time signal � 12/24-hour formats
�1�
|
|
|
> |
|
