R-2
3 ADJUSTMENTS AND CHECKS
3-1 TUNER SECTION
Use a screwdriver with a plastic or ceramic grip for all adjustment.
3-1-1 AM adjustment
1. Set the function switch to the TUNER position. 2. Set the BAND switch to the AM position. 3. Connect the test loop antenna across the output of the signal generator. 4. Connect the oscilloscope to the PHONE JACK terminal. 5. Set the signal generator as listed in the alignment chart.
3-2 Adjustment and Test Points
TC1 L3 AM ANT
L2
L1
TUNER PCB
4
