EPSON Stylus Photo R800
Revision A
5. Hold the grips of the Printer Mechanism with both hands, and remove the Printer Mechanism from the Lower Housing.
5) C.B.P 3x12 (6±1 kgf.cm) 4 6) C.B.P 3x8 (6±1 kgf.cm) 1
4.2.1.3 Lower Housing/Printer Mechanism
1. Remove the Upper Housing. (p.78) 2. Hold both ends of the two fasteners with your fingers, and shift the fasteners in the direction of arrow.
CHECK P O IN T
The 0 digit side (lower) Waste Ink Tube is marked red. However, when ink flows in the tube, the marking becomes difficult to identify. Refer to Figure 4-7 and mark the Waste Ink Tube with a red magic marker before pulling it out of the Ink Tube.
2 0 Digit Side Waste Ink Tube 10mm 5mm
Figure 4-7. Marking the Waste Ink Tube
5) C.B.P 3x12 (6±1 kgf.cm) Ink Tubes Fastener 3 5) C.B.P 3x12 (6±1 kgf.cm) Step 2 Waste Ink Tubes
3. Pull the Waste Ink Tubes from the two Ink Tubes. 4. Remove the two screws 4) C.B.S 3x8, three screws 5) C.B.P 3x12, and one screw 6) C.B.P 3x8 that secure the Printer Mechanism.
C A U T IO N
Always hold the grips when handling the Printer Mechanism. Failure to do so can deform the Frame.
Grips
4) C.B.S 3x8 (6±1 kgf.cm)
Figure 4-8. Handling the Printer Mechanism
5 6
Figure 4-9. Screws That Secure the Printer Mechanism
DISASSEMBLY & ASSEMBLY
Disassembly
80
|
|
|
> |
|
