Programming the Remote
You can customize the remote to match the components connected to your receiver. You can even program the remote to control non-Sony components and also Sony components that the remote is normally unable to control. The procedure below uses as an example a case in which a Kenwood LD player is connected to the VIDEO 2 jacks on the receiver. Before you begin note that: � You cannot change the settings of TUNER and PHONO. � The remote can control only components that accept infrared wireless control signals. Be sure to turn on the receiver and point the remote towards the receiver when performing the following procedure.
5
Move the easy scroll key to select the make of the component (�Kenwood,� for example), then press the key to enter the selection. When programming the remote to control Sony component Select �Sony.� Programming is now completed.
Using the Lists
To cancel programming Move the easy scroll key to select �EXIT� from the IR SET list, or �CANCEL� from the CATEGORY list or MAKER list, then press the key to enter the selection.
z You can change the function of the SYSTEM STANDBY switch
The SYSTEM STANDBY switch is factory set to turn off the receiver and other Sony audio/video components (i.e., �ALL OFF� setting) as described on page 5. To change the setting, move the easy scroll key to select �STANDBY� from the IR SET list in Step 3 above, then select �ON/OFF� from the STANDBY list. The switch is now set to turn on or off the receiver only.
1
Press SET UP. The set up list appears.
IR SET DOWNLOAD AUTO POWER
2
Move the easy scroll key to select �IR SET,� then press the key to enter the selection. The IR SET list appears.
STANDBY? ALL OFF ON/OFF
z You can freely assign any component to USER 1 and 2 items
in the IR SET list
1 Do Steps 1 and 2 in �Programming the Remote� on page 15. 2 Move the easy scroll key to select �USER 1� or �USER 2,� then press the key to enter the selection. 3 Continue from Step 4 in �Programming the Remote� to select the category and maker of the component.
<IR SET> [ VIDEO1 ] [ VIDEO2 ]
3
Move the easy scroll key to select the component (�VIDEO 2,� for example), then press the key to enter the selection. The CATEGORY list appears.
CATEGORY? VTR TV
4
Move the easy scroll key to select the category (i.e., the component that is actually connected to the corresponding jacks; in this case, �LD�), then press the key to enter the selection. The MAKER list appears.
MAKER? Sony DENON
16
|
|
|
> |
|
