Ersatzteilliste Spare Parts List 11 / 2004
POS. NR. ABB. POS. NO. FIG. MATERIAL-NR. ANZ. PART NUMBER QTY.
NUR F�R INTERNEN GEBRAUCH FOR INTERNAL USE ONLY
AUDIO
RRCD 3400 MP 3
MATERIAL-NR. / PART NO.: 757123425000 BESTELL-NR. / ORDER NO.: GDP5400 BEZEICHNUNG DESCRIPTION
d
RRCD 3400 MP3 CHROM TAUSCHGERAET DECKEL CASS. FEDER CD TUER DECKEL CD LAUFWERK CASS. THL-21VB-1933A TASTENSATZ CASS. KPL. LAUFWERK CD DA11-T3CN TRAGEGRIFF TELESKOPANTENNE TA78124 TUERE BATTERIEFACH BATTERIEFACHABDECKUNG FEDER CASS. TUER NETZKABEL BEDIENUNGSANLEITUNG D/GB/F/I/P/E/NL/PL/DK/S/FIN
©
RRCD 3400 MP3 CHROME EXCHANGE SET CASS. DOOR CD DOOR SPRING CD DOOR CASS. MECHANISM THL-21VB-1933 CASSETTE KNOB (SET) CD MECHANISM DA11-T3CN HANDLE FM ROD ANTENNA TA78124 BATTERY DOOR BATTERY COVER CASS. DOOR SPRING POWER CORD INSTRUCTION MANUAL D/GB/F/I/P/E/NL/PL/DK/S/FIN
757123425000
0001.000 0020.000 0021.000 0043.000 0044.000 0058.000 0078.000 0084.000 0086.000 0093.000 0094.000 0100.000
S
S
759551089300 759551089200 759551089500 759551088900 759551089800 759550615100 759551089400 759551089000 759551089700 759551089600 759551089100 759525012400 720114049000
Es gelten die Vorschriften und Sicherheitshinweise gemä� dem Service Manual "Sicherheit", Mat.-Nummer 720108000001, sowie zusätzlich die eventuell abweichenden, landesspezifischen Vorschriften!
! (!)
The regulations and safety instructions shall be valid as provided by the "Safety" Service Manual, part number 720108000001, as well as the respective national deviations.
�NDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
GRUNDIG Service
E-1
|
|
|
> |
|
