Remarks 1 Offset voltage/Master clock must be adjusted in the product condition. 2 Input signal must be CD- signal. 23 tracks of test disc(YEDS-7) 3 The adjustment for offset voltage/master clock must be done within 2 or 3 minutes from the start of product operation. 4 Master clock must be adjusted using high-frequency probe. 5 The measuring points for adjusting offset voltage must be as follows: Sensing pin land : AL2 or its equivalent land and GND Sensing pin land : AR2 or its equivalent land and GND Sensing pin land : BL2 or its equivalent land and GND Sensing pin land : BR2 or its equivalent land and GND 6 The measuring points for adjusting master clock must be as follows: TP3001 or its equivalent land and TP3002 or its equivalent GND
