This manual is accurate and of high quality. It is only volume 2 of the service manual. This is schematic, parts lists, and exploded mechanical drawings. The theory of operation and the diss-assembly instructions are in volume 1. The unit can be tricky to dis-assemble portions of so the volume 1 manual can be important. The product description of the manual is accurate but it does not say anything about volume 1 and the image of the front page does clearly say Volume 2.
 ;
Wellll again thank you very much fast and effective. Clear and well done for such an old TV!!!!
;
It has all the information you will need to fix it. The main circuit diagram is only A4 but being a PDF, you can print it to any size - I did it on two sheets of A3 and it didnt lose any detail - just made it readable when pinned up above the bench. I've found the fault, just need to buy some obscure bits to get it going again!
I cant fault the process, I paid for the manual in the morning and it was ready to download by lunch time.
;
Very good copy in a 54 pages PDF archive. This is my sixth purchase here. :)
;
Another excellent buy! File too clear and explanatory.
1
2
3
4
2.2 SPEAKER UNIT
A
For better audio quality, the receptacle terminals and terminal fittings of the speaker unit are soldered. When disassembling/reassembling the speaker unit, be sure to refer to the following figures.
Tools to be used � Hexagonal wrench (4 mm): GGK1024 � Soldering gun: GGK1069 � Lead-free solder: GYP1006 � The woofer is attached to the baffle board with 6 hexagon-socket screws from the outside. When disassembling, remove all these screws, pull out the woofer, then remove the solder to disconnect the cords. � The midrange and tweeter are integrated into a coaxial unit. This coaxial-unit speaker is attached to the baffle board with 6 hexagon-socket screws from the outside. When disassembling, remove all these screws, pull out the coaxial-unit speaker, then remove the solder to disconnect the cords.
B
When working on the woofer
Provide a stand with a height of approx. 15 cm and a piece of soft cloth for protection. Place the woofer on the cloth. To work on the woofer, drape a piece of soft cloth from around the edge of the hole where the woofer was attached to the duct, to protect the cabinet from being scratched.
When working on the coaxial-unit speaker
Drape a piece of soft cloth on the top board and place the coaxial unit on the cloth, to protect the cabinet from being scratched.
C
Piece of soft cloth
D
Piece of soft cloth
When reattaching, after connecting the cords, solder the terminals for the woofer then place the woofer so that the terminal board comes to the lower side.
When reattaching, connect the cord with black tape to the tweeter and the cord with white tape to the midrange then solder the terminals. Place the coaxial unit so that the terminal board of the midrange comes to the lower side then turn it counterclockwise slightly to secure it.
: White with Black-line
Upper side
E
Terminal size: Extra large : White with Black-line Terminal board of the tweeter Terminal size: Large Terminal size: Small : White : White with Black-line Black tape
Woofer
White tape
Upper side
: White Terminal size: Large
Coaxial unit
Terminal size: Extra large Terminal board of the midrange
White tape
F
Terminal size: Large
: White
6
1 2
S-2EX
3 4
|
|
|
> |
|
