Do the 10-ch indicator and LCD backlight light?
B
NG
OK
Is 8-V power supply active?
Check Pin 1 of the CN6503 on the PERCH PS Assy.
Does the MCACC indicator light?
C
NG
OK
NG
Failure in the LCD8V power supply
Failure in the DISPLAY microcomputer or a block of the front panel
Failure in the block of the front panel
OK
D
Failure in the Assy that cannot be controlled or poor connection between the uncontrollable Assy and other Assy
E
F
SC-09TX
5 6 7 8
45
|
