SE-M10R SE-M10R
5. SE-M10R
5.1 PARTS LIST
Mark No.
1 2 3
Description
Ear Pad Cord Assy Plug Adapter
Parts No.
WNV1098 WDE1203 WKX1033
5.2 EXPLLODED VIEW 1 2
Packing View
3
SCREW-LOCKING CONSTRUCTION TO ADJUST LENGTH OF THE BAND How to adjust the length of the headband Turn A (band adjusting screw) counterclockwise to loosen it. Slide the headband to the length you like. After deciding the length, turn A clockwise to tighten it.
DETACHABLE CORD WHICH ALLOWS CORD SELECTION ACCORDING TO THE CONNECTING EQUIPMENT Locking Method Align mark of the body bush with mark of the cord plug and insert the plug into the body firmly. Turn the cord plug clockwise to align mark of the Body bush with mark of the cord plug, and locking is complete. Unlocking Method You can unlock it by turning the cord plug counterclockwise until mark of the body bush aligns with mark of the cord plug.
6. SPECIFICATIONS
Model SE-E33SE-H33 Frequency responce 15 ~24,000Hz 20 ~20,000Hz Impedanc 16� 32� 16� 16� 35� Maximum �Input power 50mW(JEITA) 100mW(JEITA) 100mW(JEITA) 100mW(JEITA) Sensitivity 104dB/mW 104dB/mW 106dB/mW 102dB/mW Driver unit Φ16 mm Φ30 mm Φ13.5 mm Φ10 mm Φ50 mm Plug L S L L L W Cord 1.2m 1.0m 1.0m 1.2m 1.2m 7.0m Weight (Without cord) 20 g 45 g 6g 5g 275 g
SE-CN25-X1 18 ~22,000Hz SE-CL30 SE-M10R 5 ~23,000Hz 5 ~28,000Hz
3,000mW(JEITA) 106dB/mW
4
MODEL : The column of is a color sign. (X1:Black/Metal,X2:Dark Silver/Red,X3:Silver/Dark Blue,X4:Metal/Camouflage) Plug form : S (straight type) / L (L type) / W (2Way plug)
|
|
|
> |
|
