Adjustments while using the unit
Pitch control
Fine adjustment to the number of revolutions per minute.
Adjusting tone arm horizontal weight to reduce skipping when scratch playing.
The horizontal weight of the tone arm can be adjusted using the horizontal weight control knob on the gimbal suspension to reduce skipping when scratch playing. For scratch play Turn the knob all the way in the �A� direction to apply horizontal weight. For normal play Turn the knob all the way in the �B� direction to reduce horizontal weight. �Do not move the horizontal weight control knob when playing music. Horizontal weight control knob Green LED indicator Pitch control
1 2
Press [reset] to turn off the green LED light. Press [±16/±8] to select the pitch.
�When [±16/±8] is pressed once (up position), the [±16] pitch indicator lights on the pitch control slider. �When [±16/±8] is pressed twice (down position), the [± 8] pitch indicator lights on the pitch control slider.
o n
o f
reset
When the horizontal weight control knob becomes worn out
Replace with a new horizontal weight control knob. Loosen the fastening screw to remove the knob.
3
Slide [pitch adj.] while the turntable is revolving.
Move the control to the required position. �The numbers represent approximate percentages. �Pitch can be adjusted between �8 % and +8 % or �16 % and +16 %. Screw
To reset pitch to the preset value
Press [reset]. The green LED indicator lights and the pitch immediately returns to the set value (33 1/3 or 45 r/min), regardless of any adjustments made with [pitch adj.]. Press [reset] again and pitch returns to the adjusted value.
Knob
To measure pitch
The four rows of strobe mirrors around the edge of the turntable can assist you in measuring pitch. +6.4 % change in pitch when stationary +3.3 % change in pitch when stationary Normal turntable speed when stationary _3.3 % change in pitch when stationary They are lit by the strobo light as they pass and each row appears to stand still at a different pitch. Strobo light
p o we r
Consult with a qualified dealer when purchasing a horizontal weight control knob. Use the following product number when asking for the replacement. Product reference No. RGZ0053Z-S.
Adjusting the turntable brake speed
Brake speed can be adjusted by pressing [start-stop] until the turntable stops. Use a small screwdriver in the hole on the turntable to adjust the brake speed. S: Slow stop F: Fast stop
S
BRAKE
F
Read the pitch control slider replacement instructions that comes with this product carefully when replacing the pitch control slider.
0
6
Variable range pitch button
9
RQT7021
|
|
 |
> |
|
|
