SP-X2i
5 WIRING DIAGRAM
MAIN PCB
CN103 CN102
TO IPOD JACK PCB CN2
TO SPEAKER JACK PCB CN202
TO SPEAKER
TO SPEAKER JACK PCB CN201
POWER PCB
CN6 CN3
CN5
TO MAIN PCB CN101
CN1 TOLED PCB CN2
TO TRANSFORMER
12
|
|
|
> |
|
