8. ALIGNMENT PROCEDURES
TUNER 1. Equipment Requried
- AM Standard Signal Generator (AM SSG) - Oscilloscope - AC Voltmeter - FM Standard Signal Generator (FM SSG) - Stereo Modulator - Audio Generator - Distortion Meter - DC Voltmeter - Frequency Counter
2-2. AM(MW) Alignment Output of signal generator should not be greater than necessary to obtain an optimum output reading. Signal generator modulation ................................................................. 30% Signal frequency ................................................................................ 400Hz Modulation frequency ........................................... 603, 999, 1404kHz (K,N) Modulation frequency ............................................ 600, 1000, 1400kHz (U) Switch ........................................................... press the BAND Button to AM
Step
Note : Disconnect external FM antenna prior to alignment.
Subject Tunning voltage
Signal generator setting 522kHz (K,N) 520kHz (U) 603kHz (K,N) 600kHz (U)
Set frequency setting 522kHz (K,N) 520kHz (U) 603kHz (K,N) 600kHz (U) 603kHz (K,N) 600kHz (U) 999kHz (K,N) 1000kHz (U)
Equipment connection DC voltmeter
Adjustment point RF BLOCK OSC coil Adjust for 522 kHz : 1.0 ~ 1.3V 1611 kHz : 7.0 ~ 8.5V
1
2. Alignment.
2-1. Alignment Test Point
2
IF Tracking
AC voltmeter oscilloscope tape monitor L/R AC voltmeter oscilloscope tape monitor L/R AC voltmeter oscilloscope tape monitor L/R
IF BLOCK Coil KSNT-111I
Maximize audio output
3
RF Tracking
603kHz (K,N) 600kHz (U)
RF BLOCK ANT coil
Maximize audio output Repeat LOW, HIGH frequency
4
Seek level
999kHz (K,N) 1000kHz (U)
SVR 03
Tuned on point
2-3. LW Alignment (N Version only) Output of signal generator should not be greater than necessary to obtain an optimum output reading. Signal generator modulation ................................................................. 30% Signal frequency ................................................................................ 400Hz Modulation frequency ....................................................... 162, 207, 252kHz Switch ........................................................... press the BAND Button to LW
Step 1
Subject Tunning voltage
Signal generator setting 152kHz
Set frequency setting 152kHz
Equipment connection DC voltmeter
Adjustment point RF BLOCK OSC coil
Adjust for 522 kHz : 1.5 ~ 2.3V 1611 kHz : 6.0 ~ 7.5V
2
RF Tracking
162kHz
162kHz
AC voltmeter oscilloscope tape monitor L/R AC voltmeter oscilloscope tape monitor L/R
RF BLOCK ANT coil
Maximize audio output Repeat LOW, HIGH frequency
3
Seek level
207kHz
207kHz
Tuned on point
45
46
|
|
|
> |
|
