EXPLODED VIEW AND PARTS LIST
NOTE: � Items marked by asterisk ("*") are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.
3
SP2
2 2 1
SP1
2
Ref. No. 1 2 3 SP1 SP2
Part No. X-4950-949-1 4-874-614-11 A-4411-418-A 1-529-255-11 1-529-254-11
Description FRAME ASSY, GRILLE SCREW (4) (3.5 � 14), TAPPING CABINET ASSY, SPEAKER SPEAKER (16 cm) (WOOFER) SPEAKER (2 cm) (TWEETER)
Remarks
Ref. No.
Part No.
Description
Remarks
ACCESSORIES & PACKING MATERIALS ******************************** 1-769-433-22 CORD, SPEAKER 3-866-213-11 MANUAL, INSTRUCTION (ENGLISH/FRENCH/SPANISH/ PORTUGUESE/CHINESE)
Sony Corporation
9-928-820-11
Home A&V Products Company
99B1641-1D Printed in Japan ©1999.2 Published by Quality Assurance Dept. (Shinagawa)
�2�
|
|
|
> |
|
