SS-CNP76/CRP76/MSP76/VE81P/WMSP81 EXPLODED VIEWS
NOTE: � The mechanical parts with no reference number in the exploded views are not supplied. � -XX, -X mean standardized parts, so they may have some differences from the original one.
SS-CNP76
6 3 4
5
6
2
1
not supplied
SP1
Ref. No. 1 2 3 4
Part No. A-4723-985-A 4-986-971-01 4-243-839-01 4-229-803-11
Description FRONT PANEL ASSY SCREW (3.5) CABINET PACKING
Remark
Ref. No. 5 6 SP1
Part No.
Description
Remark
1-694-516-11 TERMINAL, SPEAKER 4-246-231-01 SCREW (3.5X14) 1-825-003-12 SPEAKER (7X10cm)
2
|
|
|
> |
|
