STR-DA4ES/DA7ES/VA333ES SECTION 4 DISASSEMBLY
Note: This set can be disassemble according to the following sequence.
SET 4-1. CASE (Page 12)
4-2.
PANEL ASSY (Page 13)
4-3.
BRACKET (Page 13) BACK PANEL SECTION (Page 14) DIGITAL BOARD (Page 14)
4-4.
4-5.
4-7.
A-CLASS BOARD, AMP BOARD (Page 15)
4-6.
INPUT BOARD, E-VOL BOARD (Page 15) 4-9.
4-8.
AC BOARD, CIS POWER BOARD (Page 16)
DC BOARD (Page 16)
Note: Follow the disassembly procedure in the numerical order given.
4-1. CASE
1 two screws (TP), flat head 2 two screws (TP), flat head
4 case
3 two screws (TP), flat head
12
|
