- GENERAL
- TEST MODE
- ELECTRICAL ADJUSTMENTS
- DIAGRAMS
- Circuit Boards Location
- Schematic Diagram - Tuner Section
- Printed Wiring Board - Tuner Section
- Schematic Diagram - Display Section
- Printed Wiring Board - Display Section
- IC Pin Function
- IC Block Diagrams
- EXPLODED VIEW
- ELECTRICAL PARTS LIST
There are currently no product reviews.
 ;
Very usrfull for repaur, great quality copy. includes complete parts list and schematics
;
Good quality Service Manual, availability of components includes disassembly, electronic adjustments. Includes a full list of details and diagrams. Contains 58 pages.
 ;
y'm hapy for this shoping . Estoy feliz por esta compra , ahora puedo reparar mi equipo de audio que AMO . And very good price for this manual . Thank yuo .
;
Perfect manual, perfect service. Easy reading. Thanks a lot
;
Very good quality download here. Great hard to find manuals at a reasonable price.
SECTION 2 TEST MODE
1. Circuit Check Mode Set to the reception frequency that the circuit can STEREO RDS stations. (Set the input level to above 70 dB.) This enables circuit check to be performed in any of the reception modes-FM, AM (MW, LW). Set to a desired band before setting the test mode. 1. Turn OFF the power. 2. While pressing 4 and AUTO-BETICAL SELECT together, turn ON ! . � The items in the following table will be checked automatically in order every 2 seconds.
Display Tuned IF Frq Sig Level Stereo RDS Signal
Items
AST signal =LOW IF COUNT OK SI LEVELh70dB ST signal=LOW RDS DATA OK
DISPLAY
FM RDS
OK or NG OK or NG OK or NG OK or NG OK or NG
AM (MW, LW)
NG IC201 NG, RV201 adjustments
OK or NG OK or NG
TB101, IC201 NG TB101 NG TB101 NG IC802 NG
3
|
|
|
> |
|
