SPECIFICATIONS
<FM Tuner section> Tuning range Usable sensitivity(IHF) Antenna terminals <AM Tuner section> Tuning range Usable sensitivity Antenna 87.5 MHz to 108 MHz 13.2 dBf 75 ohms (unbalanced) <Compact disc player section> Laser Semiconductor laser (λ =780 nm) D-A converter 1 bit dual Signal-to-noise ratio 85 dB (1 kHz, 0 dB) Harmonic distortion 0.05 % (1 kHz, 0 dB) Wow and flutter Unmeasurable <Speaker system SX�WNSZ70> Speaker system 3 way, Built-in subwoofer(magnetic shielded type Speaker units Subwoofer : 160 mm cone type Full range: 100 mm cone type Super Tweeter : 20 mm ceramic type Impedance 6 ohms / 8 ohms Sensitivity 87 dB/W/m Dimensions (W x H x D) 240 x 324 x 281 mm Weight 5.0 kg <General> Power requirements Power consumption Power consumption in standby mode
530 kHz to 1710 kHz (10 kHz step) 531 kHz to 1602 kHz (9 kHz step) 350 uV/m Loop antenna
<Amplifier section> Mid-high frequency amplifier Power output Rated: 32 W + 32 W (8 ohms, T.H.D. 1 %,1 kHz) Reference: 40 W + 40 W (8 ohms, T.H.D. 10 %,1 kHz) Total harmonic distortion 0.1 % (15 W, 1 kHz, 8 ohms, DIN AUDIO) Low frequency amplifier Power output Rated: 96 W + 96 W (6 ohms, T.H.D. 1 %, 135 Hz) Reference: 120 W + 120 W (6 ohms, T.H.D. 10 %,135 Hz) Total harmonic distortion 0.1 % (50 W,135 Hz,6 ohms, DIN AUDIO) Inputs VIDEO/AUX : 300 mV (adjustable) MD: 316 mV (adjustable) MIC: 1.8 mV (10 kohms) Outputs SPEAKERS HIGH FREQ : accept speakers of 8 ohms or more SPEAKERS LOW FREQ : accept speakers of 6 ohms or more SURROUND SPEAKERS : accept speakers of 8 to 16 ohms LINE OUT: 210 mV PHONES (stereo jack) : accepts headphones of 32 ohms or more <Cassette deck section> Track format Frequency response Recording system Heads
Dimensions (W x H x D) Weight
120 V/220-230 V/240 V switchable, 50/60Hz 200W If the power-economizing mode is ECO OFF: 21 W If the power-economizing mode is ECO ON or ECO AUTO: 0.9 W 260 x 330 x 395mm 9.5 kg
� Design and specifications are subject to change without notice.
� The word "BBE"and the "BBE symbol" are trademarks of BBE Sound, Inc. Under license from BBE Sound,Inc.
4 tracks, 2 channels stereo CrO2 tape: 50 Hz � 16000 Hz Normal tape: 50 Hz � 15000 Hz AC bias Deck 1: Playback head x 1 Deck 2: Recording/Playback head x 1, erase head x 1
ACCESSORIES / PACKAGE LIST
REF. NO. 1 2 3 4 5
PART NO.
!
KANRI NO. 8A-NF7-932-010 87-006-225-010 87-043-115-010 87-A91-017-010 8Z-NF8-702-010
DESCRIPTION IB,LH-KIT (BRA) AM LOOP ANT NC2 ANT,FEEDER FM PLUG,CONVERSION JT-0476 RC UNIT,RC-ZAS01
-2-
|
|
|
> |
|
