DISASSEMBLY INSTRUCTIONS
1. Remove machine screws M4.0 x 8.0 (1 to 6) from the side panels. Remove tapping screw 3.0 x 8.0 (7 to 10) from the back panel. Refer to Figure No. 1.
9 10 8 3
1 7
2 6 4
5
Figure No. 1
2.
Pull both sides of the TOP COVER slightly outwards 11 and tilt approx. 35 ° and then remove in the direction as indicated by the arrow 12. Refer to Figure No. 2.
12
11
11
Figure No. 2
7
 $4.99 T762 NAD
Owner's Manual Complete owner's manual in digital format. The manual will be available for download as PDF file aft…
|
