2. NOTES ON DISASSEMBLING AND REASSEMBLING
Cleaning
Use a soft cloth to wipe off dirt and foreign matter, such as fingerprints, from the cabinet after repair. (Do NOT use silk cloth because its fibers are coarse and may easily scratch the cabinet.)
A
2.1 DISASSEMBLING AND REASSEMBLING OF THE CST UNIT
Note: The CST unit can be disassembled or reassembled with the cabinet in the upright position. 1. To remove the gasket, thrust an eyeleteer or the blade of a cutter into the gap between the gasket and its surrounding. If the gasket is damaged while being removed, replace it. 2. Remove the screws that secure the CST unit. 3. For reassembling, see "2.3 CABLE CONNECTION AND LOCATION OF THE TERMINALS OF THE SPEAKER UNIT." When reattaching the gasket, push it in so that the gasket is level with the trim ring. Tools to be used: � Hexagonal wrench, Size 3 mm (for the fixing screws of the CST unit) � Eyeleteer or cutter (for the gasket)
B
2.2 DISASSEMBLING AND REASSEMBLING OF THE WOOFER UNIT
1. For protection of the speaker cabinet, lay several blankets or equivalents to obtain sufficient cushioning. Lay the speaker on the blankets, as shown in the upper figure. 2. Thrust an eyeleteer or a similar tool into the gap between the screw caps and the cabinet and pull them out. As the screw caps cannot be reused, procure new ones in advance. 3. Remove the screws from the speaker unit then remove the woofer unit. As the woofer unit is quite heavy, if all the screws are removed with the speaker unit placed on its side as shown in Step 1, the speakers may come off and damage the baffle. Therefore, before removing the last screw, have two people hold the speaker unit so that the speakers face upward, as shown in the lower figure. 4. For reassembling, see "2.3 CABLE CONNECTION AND LOCATION OF THE TERMINALS OF THE SPEAKER UNIT." When securing the screws, to fix the speakers in the right positions, have two people hold the speaker unit so that the speakers face upward. 5. Install the new screw caps. Tools to be used: � Hexagonal wrench, Size 4 mm (for the fixing screws of the woofer unit) � Eyeleteer (for the screw caps) � Screw caps SNK2943, 6/unit
Blankets Use several blankets to obtain sufficient cushioning.
C
Blankets
D
E
F
TAD-R1
