MAIN BOARD, MECHANISM DECK (MT-40-118)
Note: On installation MAIN board adjust the S105 and button (pause).
6 three screws (IB lock) 7 claw
button (pause)
8 mechanism deck (MT-40-118)
1 Remove four solders of motor leads (M901).
S105
5 MAIN board 2 Remove the two solders screw 4 of the head lead (HRP901). (M1.4) 3 screw (1.7)
NOTE FOR INSTALLATION
� MAIN BOARD On installation MAIN board adjust the S101 and REC lever.
screw (1.7) screw (M1.4)
MAIN board
S101
REC lever
�5�
|
