Caratteristiche tecniche
SEZIONE SINTONIZZATORE FM
Campo di sintonia ....................................................... 87,5 � 108,0 MHz Sensibilità utilizzabile mono/ ......................................................... 0,7 µV Soglia di sensibilità 50 dB ............................................................. 1,1 µV Selettività canali alternativi ............................................................ 80 dB Rapporto segnale/rumore .............................................................. 65 dB Separazione stereo ........................................................................ 35 dB
Italiano
TELECOMANDO
Tipo di pile.. ................................................. Pile a secco formato "AAA" Numero di pile... ................................................................................... 2 Dimensioni (L � A � P).. ................................ 56 mm � 14 mm � 105 mm Peso (senza pile)... ........................................................................... 50 g
GENERALI
Alimentazione ................................... 14,4 V DC (11 � 16 V (consenita)) Uscita di potenza massima* ........................................................... 40 W � 4 Tensione di preuscita massima .......................................... 2V/10k ohms Bass ................................................................................... ±15 dB/30 Hz Acuti ................................................................................. ±10 dB/10 kHz Peso .............................................................................................. 1,4 kg
SEZIONE SINTONIZZATORE OM
Campo di sintonia ......................................................... 531 � 1.602 kHz Sensibilità (standard IEC) ................................................. 25,1 µV/28 dB
SEZIONE SINTONIZZATORE OL
Campo di sintonia ............................................................ 153 � 281 kHz Sensibilità (standard IEC) ................................................. 31,6 µV/30 dB
DIMENSIONI DEL TELAIO
Larghezza .................................................................................. 178 mm Altezza ......................................................................................... 50 mm Profondità .................................................................................. 150 mm
SEZIONE LETTORE DI NASTRI
Velocità del nastro ...................................................... 4,8 cm/sec ±0,7% Wow e flutter ..................................................................... 0,07% WRMS Rapporto segnale/rumore Con il Dolby NR tipo B .............................................................. 68 dB Con il Dolby NR tipo C (solo TDA-7568R) ................................. 75 dB Senza Dolby NR ......................................................................... 60 dB Risposta in frequenza Con nastri di prova Alpine ........................................... 30 � 20.000 Hz IL PRODUTTORE ALPINE ELECTRONICS INC. DI QUESTO APPARECCHIO MODELLO TDA-7568R/TDA-7566R DICHIARA CHE ESSO E CONFORME AL D.M. 28.08.1995 N.548. OTTEMPERANDO ALLE PRESCRIZIONI DI CUI AL D.M.25.6.1985 (PRAGRAFO 3. ALL A) ED AL D.M. 27.8.1987 (PARAGRAFO 3. ALL 1)
DIMENSIONI DELLA PARTE ANTERIORE
Larghezza .................................................................................. 170 mm Altezza ......................................................................................... 46 mm Profondità .................................................................................... 22 mm
Nota: A causa di continui miglioramenti del prodotto, le caratteristiche tecniche e il design sono soggetti a variazioni senza preavviso. * A massimo di tensione operativa e segnale in ingresso, a 4 ohm.
