Text excerpt from page 10 (click to view)
Adjusting the Lowest Level of the Backlight
The minimum brightness level for the backlighting (LOW) is adjustable. This is used to match the screen brightness to the dashboard (especially at night). This setting is recalled whenever the vehicle�s headlight switch is turned on in the AUTO Dimmer mode.
Setting Automatic Closing of Monitor
Simply turn the ignition key to OFF to automatically close the monitor display.
9
9
1 2 3
Press the SETUP button. Press the 9 or 8 button within 10 seconds to select AT CLOSE. Press the the value. or button within 10 seconds to set
1 2 3
Press the SETUP button. Press the 9 or 8 button within 10 seconds and select DIMMER Lv. Press the the value. or button within 10 seconds to set
AUTO: Automatic closing of the display in depending upon whether the ignition switch is ON or OFF. If you press the POWER button or the OPEN/ CLOSE button while the monitor is being opened or closed, the monitor stops opening or closing, even if AUTO setting is on, and cannot be closed
FR
SET UP
AUX1 DIMMER AUTO DIMMER Lv. AT CLOSE OFF
LOW HIGH
PAGE 2
4
Press the SETUP button to finish adjustments.
OFF: Manual closing of the display.
SET UP
AUX1 DIMMER AUTO DIMMER Lv. AT CLOSE OFF PAGE 2
9
automatically. In this case, press the POWER button or the OPEN/ CLOSE button again to close the monitor.
