SPECIFICATIONS
Track system Frequency response Microphone Maximum output: Output jack Other jack Speaker Recording system Erasing system Power sources: Battery life Battery Manganese (R6P) batteries Alkaline (LR6) batteries EIAJ Recording Approx. 5 hrs Approx. 19 hrs EIAJ 10 mW Approx. 4 hrs Approx. 15 hrs 2 tracks 1 channel, monaural 250 � 8,000 Hz EIAJ Electret condenser microphone (monaural) 300 mW (EIAJ/DC) EARPHONE jack (monaural mini-jack)(1) DC 3 V jack Diameter 50 mm, 8 ohms DC bias Magnet erasure DC 3 V using two R6 (size AA) dry cell battery AC house current using the AC adaptor Aiwa AC-D302
Maximum outside dimensions: 111.7 (W) x 84.3 (H) x 33.4 (D) mm (excluding projecting parts and controls) Weight: Approx.152 g (excluding batteries)
� Design and specifications are subject to change without notice.
ACCESSORIES / PACKAGE LIST
REF.NO. 1 1 KANRI DESCRIPTION NO. 8A-HTB-902-010 IB,YHJ(ECC)S 8A-HTB-903-010 IB,YJ (ECA)S PART NO.
�2�
|
|
|
> |
|
