PRACTICAL SERVICE FIGURE
Tape speed: Wow & flutter: Take-up torque: F.F torque: REW torque: S/N ratio: Distortion: Noise level: 3000 Hz ± 60 Hz Less than 0.55% (4.8 cm/s) Less than 0.8% (2.4 cm/s) 20 ~ 50 g-cm (FWD) More than 55 g-cm More than 55 g-cm More than 56 dB (DC, PB) More than 26 dB (DC, R/PB) Less than 3.0% (DC, PB) Less than 7.0% (DC, R/PB) Less than 2.0 mV (PB, Vol Max., DC) Less than 16 mV (R/PB, Vol Max., DC) Less than 0.3 mV (PB, Vol Min, DC) Erasing ratio: Test tape More than 44 dB (1kHz) TTA-100 TTA-330
IC BLOCK DIAGRAM
IC, MM1206XF
TRANSISTOR ILLUSTRATION
C
B
E 2SC2712 2SC3326 2SC4081 2SC4116 2SC4213 DTC114
