SPECIFICATIONS
Track system Frequency response Microphone Maximum output Input jack Output jack Other jack Speaker Recording system Erasing system Power sources Battery life 2 tracks 1 channel, monaural 250 � 8,000 Hz EIAJ Electret condenser microphone (monaural) 300 mW (EIAJ/DC) EXT MIC jack (monaural mini-jack) (1) EARPHONE jack (monaural mini-jack) (1) DC 3 V jack Diameter 50 mm, 8 ohms DC bias Magnet erasure DC 3 V using two R6 (size AA) dry cell batteries AC house current using the AC adaptor Aiwa AC�D302 Battery EIAJ Recording EIAJ 10 mW Manganese (R6P) batteries Approx. 5 hrs Approx. 4 hrs Approx. 15 hrs
Alkaline (LR6) batteries Approx. 19 hrs Maximum outside dimensions 111.7 (W) x 84.3 (H) x 33.6 (D) mm (excluding projecting parts and controls) Weight Approx.152 g (excluding batteries) � Design and specifications are subject to change without notice.
ACCESSORIES / PACKAGE LIST
REF. NO. PART NO. 1 1 1 1 1 1 2 8A-HTA-905-010 8A-HTA-907-010 8A-HTA-906-010 8A-HTA-902-010 8A-HTA-903-010 8A-HTA-904-010 87-PD3-050-010
KANRI DESCRIPTION NO. IB,Y(EGF)S<Y> IB,Y(PHNCZ)S<Y> IB,Y(SID)S<Y> IB,YHJ(ECC)S<YH,YHT> IB,YJ(ECA)S<YJ> IB,YL(3L)S<YL> STRAP,HAND
