SPECIFICATIONS
INPUT 1 jack INPUT 2 terminals Input sensitivity/Impedance INPUT 1: 1 V / 50 kilo ohms (at 60 Hz) INPUT 2: 9 V / 4.4 kilo ohms (L and R) (at 60 Hz) Output terminals SPEAKERS OUT terminals Power output FTC RULE 120 watts, Min. RMS at 4 ohms, from 40 Hz to 160 Hz, with no more than 1 % Total Harmonic Distortion 120 W (4 ohms, T.H.D. 1 % at 60 Hz) 150 W (4 ohms, T.H.D. 10 % at 60 Hz) DIN MUSIC POWER: 220W Frequency response 35 Hz � 200 Hz Speaker type Bass reflex type Speaker unit 20 cm (Magnetically shielded type) Power requirement AC 120 V / 220 V � 240 V switchable, 50 / 60 Hz Power consumption 65 W Dimensions (w/h/d) 295 x 340 x 430 mm (115/ x 131/ x 17 inches.)
8 2
Input terminals
Weight
11.5 kg (25 lbs 6 oz.)
� Design and specifications are subject to change without notice.
-2-
|
|
|
> |
|
