MECHANICAL PARTS LIST 1 / 1
REF. NO. 1 1 2 2 2 2 3 3 4 4 5 5 6 6 6 6 7 8 8 9 9 9 10 11 12 12 13 14 14 15 16 16 A B B C D
PART NO.
KANRI NO. 8Z-JBV-005-010 8Z-JBT-005-010 8Z-JB8-002-210 8Z-JB6-011-010 8Z-JB8-018-010 8Z-JB8-017-010 8Z-JBV-008-010 8Z-JBT-008-010 8Z-JBV-009-010 8Z-JBT-009-010 87-054-087-010 87-054-086-010 8Z-JB8-001-110 8Z-JB8-016-010 8Z-JB6-001-010 8Z-JB8-021-010 8Z-JBS-205-010 8Z-JB8-640-010 8Z-JB6-625-010 87-JB9-602-010 86-LB7-606-010 86-LB7-608-010 84-LB3-205-010 8Z-JB8-005-010 8Z-JB6-004-010 8Z-JB8-004-010 8Z-JBV-641-010 87-A90-332-010 87-A90-848-010 8Z-JB6-695-010 8Z-JBV-007-110 8Z-JBT-007-110 87-067-680-010 87-078-203-110 86-LBB-206-010 87-067-844-010 87-067-761-010
DESCRIPTION KEY,MAIN<143,1418> KEY,MAIN<2018> PANEL,FR C143KER<143> PANEL,FR C2018 BL<2018> PANEL,FR C1418 BL<1418KER7S4M> PANEL,FR C1418 SL<1418KER7L4M> LENS,LED<143,1418> LENS,LED<2018> LENS,RC<143,1418> LENS,RC<2018> BADGE,AIWA 40<143,1418> BADGE,AIWA 52.5 ABS GLD<2018> CABI,FR 2SP<1418KER7S4M> CABI,FR 2SP BL<1418KER7L4M> CABI,FR 2SP<2018> CABI,FR 2SP GR<143> W-G,10-20-2 DGC,14 9OHM VRK<143,1418> DGC,20 15OHM VRK<2018> CRT,A48AGY13X67N<2018> CRT,A34AGT13X79N<1418> CRT,A34JXV70X10N00<143> SPR-E,EARTH PLATE,REAR 4HL CABI,REAR 4HL<2018> CABI,REAR 4HL<143,1418> SPKR,F 80 8OHM 2W HLDR,SF-2001 HV CABLE<1418,2018> HLDR,HV CABLE DIT<143> AC CORD SET,KE BLK BTN,POWER 2<143,1418> BTN,POWER 2<2018> BVI T3+3-10 S-SCREW,W5-25<143,1418> S-SCREW,ASSY TV5-40 W20<2018> BVT2+4-16 BLK TAPPING SCREW, BVT2+3-10
REF. NO.
PART NO.
KANRI NO.
DESCRIPTION
! ! !
! !
!
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color B Black C Cream D Orange G Green H Gray L Blue LT Transparent Blue N Gold P Pink R Red S Silver ST Titan Silver T Brown V Violet W White WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green LD Dark Blue DT Transparent Orange GM Metallic Green YM Metallic Yellow DM Metallic Orange PT Transparent Pink LA Aqua Blue
� 12 �
|
|
|
> |
|
