SECTION 7 SPARE PARTS
7-1. NOTES ON REPAIR PARTS
(1) Safety Related Components Warning Components marked ! are critical to safe operation. Therefore, specified parts should be used in the case of replacement. (2) Standardization of Parts Repair parts supplied from Sony Parts Center may not be always identical with the parts which actually in use due to �accommodating the improved parts and/or engineering changes� or �standardization of genuine parts�. This manual's exploded views and electrical spare parts list are indicating the part numbers of �the standardized genuine parts at present� . (3) Stock of Parts Parts marked with �o� SP (Supply Code) column of the spare parts list are not normally required for routine service work. Orders for parts marked with �o� will be processed, but allow for additional delivery time. (4) Units for Capacitors, Inductors and Resistors The following units are assumed in schematic diagrams, electrical parts list and exploded views unless otherwise specified. Capacitors : µF Inductors : µH Resistors : Z
