CA-2 board (Side B)
G Cy mg
2-11. CCD White Point Defect Detect Adjustment
Measuring location: VIDEO OUT Measuring equipment: Monitor display Adjustment method: 1. Shield light with a lens cap to provide dark condition. 2. Set the camera mode, and click the �AUTO� at the WDD on the adjustment software. 3. After completing this adjustment, it comfirms that white point can not be seen on the monitor display. 4. Click the End button.
