Installation of [3] and [6]
First, insert [6] diagonally in [3] as shown below. Then, install [6] in [3] while pushing (L-1) in a direction of arrow. After installing [6] in [3], confirm that pin A of [3]
Fig. DM3H
enters hole A of [6] properly. [3]
Pin D Pin C [2] A 1 2 Pull up Slide View for A
1 (L-1) 2 [6] Hole A Pin A
Installation of [4] and [6]
Install [6] in [4] while pulling (L-2) in a direction of arrow. After installing [6] in [4], confirm that pin B of [4] enters hole B of [6] properly.
Pin A
[4] Pin B Slot A View for B Hole B Pin B (L-2) [6]
Slots B
Fig. DM5H
Slot A First, while pushing the locking tab as shown in the right, slide and pull up the right side on [2] to release Pin A and Pin B from the slots A. Then, remove Pin C and Pin D on [2] from the slots B as shown. Locking tab View for A
Fig. DM4H
4-7
|
|
|
> |
|
