Installation for Antenna Unit
1. Mount the antenna main unit to the mounting bracket and check the locations where the antenna are to be fixed. Open the antenna and extended to full length. Adjust tilting and flip-up angles to confirm the actual use condition. 2. Remove the main unit from the mounting bracket. To remove, slide the release button to release the lock and lift the rear end of the main unit up as shown in the figure and slide the main unit forward.
Rear windshield
Fixing area
English
Rear defogger heater
Main unit (for left side) Mounting bracket
4. Remove the protective sheet from the double-sided tape on the mounting bracket and press firmly on to the rear windshield to fix. When fixing to the body etc, use supplied protective tape (Accessory@3)for protecting the body paint, if necessary.
Protective sheet of double-sided tape
Release button Mounting bracket
3. Clean off any grease or dirt from the fixing area for mounting bracket and cable holder, using supplied cleaning cloth(Accessory!8).
CAUTION
CAUTION
Warm up the rear windshield by rear defogger heater, if the surface temperature of the rear windshield is low. Fixing parts with the double-sided tape should be done indoor, on the day of high humidity such as on a rainy day even if the surface to be fixed is not wet. Low surface temperature and high humidity may not only weaken the adhesive strength of the double-sided tape, but also cause it to come loose.
Clean the window glass thoroughly, as failure to clean the glass can not only weaken the adhesive strength of the double-sided tape, but also cause it to come loose.
39
|
|
|
> |
|
