is part of the manual is very useful for repairing
Here are circuit diagrams
if there is damage, I recommend using this part of the
a complete list of circuit boards and components
2-4.
MECHANISM DECK
2 Remove the mechanism deck in the direction of the arrow,
1 Insert the precision screwdriver (1.4 mm flat-blabe) in to the slit and release two claws.
2-5.
BELT, MOTOR (REEL/CAPSTAN)
2 Two screws [screw (M 1.4), special head]
3 Motor (reel/capstan)
1 Belt
�5�
|
