2-3. MAIN BOARD
1 Head flexible board
2 Remove the solder of the motor wire.
4 Main board
3 Claws
2-4. CASSETTE LID
B
Note: When the Cassette lid is installed to the unit, Pass the flexible board through a square hole.
A 2 Release the catch B.
1 Release the catch A.
Front cabinet
3 Cassette lid (Remove it in the direction of the arrow)
�4�
|
|
|
> |
|
