MAIN BOARD
1 claw
2 guide (board)
3 Remove the solders of motoer (M901) and terminal board ass'y battery.
8
MAIN board
4 screw 5 terminal board ass'y, battery 7 screw (IB lock)
6 flexible board (CN301)
3 Remove the solders of plunger solenoid.
Note on installation: When the MAIN board, align the switch (S702) with the lever (SW) correctly.
S702
lever (SW)
