RADIO OPERATION
Tuning 1 Press the POWER / ON/STANDBY button to turn
the power on. 2 Press the TUNER (BAND) button. 3 Press the TUNER (BAND) button to select the desired frequency band. (FM ST, FM or AM) 4 Press the TUNING/TIME (%UP or �DOWN) button to tune into the desired station.
1 2,3, 5,6
Manual tuning : 4
Press the TUNING/TIME (%UP or �DOWN) button as many times as required to adjust the frequency shown on the display to the frequency of the desired station.
Auto tuning :
When the TUNING/TIME (%UP or �DOWN) button is pressed for more than 0.5 second, scanning will start automatically and the tuner will stop at the first receivable broadcast station.
4 1
2,3, 5,6
Notes : � When radio interference occurs during auto scan � �
tuning, auto scan tuning may stop automatically at that point. If a weak station signal is found during auto scan tuning, the station will be skipped. To stop the auto tuning, press the TUNING/TIME (%UP or �DOWN) button again.
5 To receive an FM stereo transmission, press the � After use :
Press the POWER / ON/STANDBY button to enter the standby mode TUNER (BAND) button so that the �ST. indica� tor on the display lights up. � � will light up when an FM broadcast is in stereo. If the FM reception is weak, press the TUNER (BAND) button so that the �ST. indicator goes � off. The reception changes to mono, the sound becomes clearer.
6 �
Note : � The last station turned in will be recalled, even
after changing the tuning band or the function, or after switching the unit to the standby mode.
18 EN
|
|
|
> |
|
