XV-HTD510, XV-HTD510-B
TRAVERSE MECHANISM ASSY-S Disassembly 1 2
Remove the Bonnet (Screws � 7) Remove the Tray Cap Remove the Front Panel Section (Refer to " FRONT PANEL SECTION")
8
Unhook
CN12
9 7
TRSB Assy
9
Unhook
3 4 5 6 7 8 9
Power ON Tray Open (0 OPEN/CLOSE) Pull out the power cord from the outlet. Push the Tray by hand. (about 5 cm) Bring an extra flexible cable close to the rear side. Disconnect the flexible cable. Note : The Traverse mechanism being an unclamp (=down) state.
Unhook � 2 while pressing the two hooks ( 9 ).
10 Pull out the tray 10
6
Tray Section
When Tray Cannot Pull Out
Tray cannot pull out that is not at a position of home position. (When two hooks ( 9 ) hide under the Rotary Tray and can not pull out the tray.) In that case, set the tray in the following procedures. 1 Remove
3
Tighten
Note : Do not need to match with Disc No. (1 to 5) when returns the tray. Detect it automatically.
Rotary Tray
2
Set the tray to the position that can see a hole of the center.
87
|
|
|
> |
|
