MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage. AHR ....................XX..................................A................... AHC ....................XX...................................B.................. AHK ....................XX....................................C................. KANRI REF.NO PARTS NO. NO. DESCRIPTION SUFFIX 88-HC6-021-010 FOOT, DIA10 88-HV2-001-010 LID,CD 88-HV2-002-010 CABI,CENTER 88-HV2-007-010 KEY,PLAY 88-HV2-008-010 KEY,SKIP 88-HV2-009-010 KNOB,SL OPEN 88-HV2-010-010 KNOB,SL A 88-HV2-011-010 KNOB,SL B 88-HV2-006-010 WINDOW,DISPLAY 88-HV2-012-010 WINDOW,SENSOR 88-HV2-013-010 HLDR,LID CD 88-HV1-207-010 DMPR,MECHA 88-HV2-201-010 HLDR,LCD 88-HV2-202-010 PLATE,LCD 88-HV2-203-010 SPR-T,LID 88-HV2-204-010 BAT-CONTACT,(+) 88-HV2-205-010 BAT-CONTACT,(-) 88-HV2-206-010 BAT-CONTACT,(+)(-) 88-HV2-208-010 SPR-T,KNOB 88-HV2-209-010 LEVER,OPEN 88-HV2-210-010 HLDR,OPEN 87-067-732-010 0E TAPPING SCREW, VT1.4-3 87-067-869-010 0E V+1.7-8 HL BLK 88-HV2-604-010 FF-CABLE, 10P 1 ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC................. ABC.................
|
|
|
> |
|
