The service was quick and simple, finding the service manual easy and it appears to be the original with colour schematics. It contained the info I was after and so sorted the problem.
I have copied it to CD and attached the envelope to the inside back cover of the owners manual. Good manual and excelent service. Robin Wood, Wood Electronics, New Zealand.
;
Exactly what was needed to assess the product - excellent value and great service
 ;
Nice to have the service manual for the Sony DCR-TRV345E now. The document is of excellent quality.
;
MACKIE HR824 26 pages English-only Service Manual contains:
1) HR824 technical overview with the description of front and rear panel switches.
2) HR824 specs
3) Block Diagram
4) Wiring Diagram
5) Packaging management
6) Spare part & final assembly list (for PCB rev A and B) + exploded view
7) Test Procedures (where, how to measure voltage...) including Test Point diagram on the PCB.
8) IC and Transistor charts.
Excellent guide: very clear, good scan quality enabling us to print readable diagram :-)
Note:
Mackie HR824 make extensive use of surface mount devices (SMD). Service on the HR824 must
only be undertaken by experienced service technicians with the right tools, experience and patience to perform surface mount rework when needed.
;
This Service manual is very well scanned and its clean to read, no any anti-theft words that un-english could understand. I got my CCD600 working with this manual and it´s clear shematics :)
Pin No. 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 ~ 79 80
Pin Name MUTE STANDBY LCDRDO P-OFF DSCHRG CHRG BAT-F BAT-M BAT-E TX-ON SWCL EL-ON SPCON CAR-LED E-MODE TEST M1/NM2 NC SEG15 ~ 0 NC
I/O O O O O O O O O O I O O O I I I O Audio mute output.
Description
Headphone standby output. Standby at �L�. Power ON at �H�. Wired LCD remote control output. Power IC power off output. Power OFF at �L�. Electric discharge output. Electric charge output. Battery balance indication full indication LED output. (Not used) Battery balance indication medium indication LED output. (Not used) Battery balance indication empty indication LED output. (Not used) Not used. Cover open/close detection SW input. EL back light control output. Spindle PWM control output. (Not used) CAR-KIT model button LED light on output. (Not used) Shaft damage mode (Not shaft damage mode found out �H�). (Not used) Enter test mode at �L�. (Not used) 10 or 10/40 sec selection input. 10 sec at �H�, 10/40 sec at �L�. (Not used) Not connected. LCD segment output. Not connected.
