Pin No. 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
Pin Name FSYNC CRCF DVDD6 VSS WOK CNTOK 0VF CMDOUT CMDIN CL MP3_CE INTB RESB DATAIN DATACK
I/O O O � � I O
Description MP3 frame syncronization signal. H: active. CDROM-CRC flag output / DRAM data output enable signal output. H: active. I/O digital supply pin. GND pin. DRAM write permit input (CD DA) / DRAM data demand flag input (CDROM). H: active. Data connection point detection completion flag (CD DA) / DRAM data serial output (CDROM). H: active.
O O I I I O I I I
DRAM write interrupt flag (CD DA) / DRAM data transfer clock output (CDROM). H: active. Command serial data output. (Nch open drain output pin) Command serial data input. Command serial clock input. Command enable input. H: active. Interrupt signal output. L: active. System reset. L: active. CD serial data input. CD bit clock input.
� 19 �
 $4.99 XPZ3 AIWA
Owner's Manual Complete owner's manual in digital format. The manual will be available for download as PDF file aft…
|
|
|
> |
|
