If only one track is titled on the tracks to be combined, this title remains. NOTE You can not combine a track recorded in monaural and a track recorded in stereo.
CHANGING THE ORDER OF THE TRACKS
You can change the order of tracks after completing a recording. The order does not go back to the original order even when the power turns off.
Example To move the 3rd track to the 1st position.
1 Press the MD button and insert an MD. 2 Select the track that you want to move with MULTI JOG or the numbered buttons on the remote control. Example: To move the 3rd track, select the 3rd track. 3 Press the MD EDIT button repeatedly until "Move" is displayed.
4 Within 10 seconds, press the ENTER button. 5 Turn the MULTI JOG control to select the desired track number to move the track to. Example: The 3rd track moves to the 1st position
 $4.99 XRH33MD AIWA
Owner's Manual Complete owner's manual in digital format. The manual will be available for download as PDF file aft…
|
