Ver 1.1 2000.08
7-3.
UPPER CABINET SECTION
Ref. No. 101 102 103 104 105 106 107 108 108 109 110 * 111
Part No. X-3372-903-1 X-3372-904-1 3-939-032-01 3-939-033-01 3-939-031-01 3-939-030-01 3-351-377-31 X-3373-690-1 X-3373-692-1 3-939-038-01
Description CASSETTE HOLDER (A) ASSY CASSETTE HOLDER (B) ASSY SPRING (A), CASSETTE UP SPRING (B), CASSETTE UP SPRING, PUSH CATCHER RETURN
Remarks
Ref. No. * 111 112 113 * 114 * 114 * 115 * 115 116 * 117 * 117 118 ANT2 ND451
Part No. A-3306-457-A 3-939-028-01 3-939-029-01 A-3306-447-A A-3306-458-A 1-662-762-13 1-662-762-21 1-777-641-11 A-3293-409-A A-3293-412-A
Description
Remarks
CONTROL BOARD, COMPLETE (AEP,UK,IT) HOLDER, LCD ILLUMINATOR LCD BOARD, COMPLETE (CND) LCD BOARD, COMPLETE (AEP,UK,IT) LAMP BOARD (CND) LAMP BOARD (AEP,UK,IT) WIRE, PARALLEL (FFC) (8 CORE) MAIN BOARD, COMPLETE (CND) MAIN BOARD, COMPLETE (AEP,UK,IT)
CATCHER, PUSH DAMPER CABINET (UPPER) SUB ASSY (CND) CABINET (UPPER) SUB ASSY (AEP,UK,IT) GEAR, HANDLE
1-777-640-11 WIRE, PARALLEL (FFC) (12 CORE) A-3306-446-A CONTROL BOARD, COMPLETE (CND)
3-939-034-01 TERMINAL, ANTENNA 1-501-861-11 ANTENNA, TELESCOPIC 1-801-465-11 DISPLAY PANEL, LIQUID CRYSTAL
� 79 �
|
|
|
> |
|
