As the only source for this manual it rather rank quite high since it is well scanned and perfectly readable.
 ;
the manual is in good quality and it's in pdf. manual was send in less then 24h.
regards
mike
;
I would not plug this machine in without finding a manual like this. In addition to setup and normal operating instructions, it has troubleshooting flowcharts, diagrammed mechanical adjustments, and schematics to beat the band. The tech I hand it to would be thrilled to find solder side PCB diagrams with component outlines superimposed, pinouts for every IC chip, and line drawings of transistors, with labeled legs.
As for printing quality, this may be a copy of a copy, but even the finest print when enlarged is very legible. There is a bit of grayed print over a few pages, as if a wet page were placed over it, but the print is still very legible. If you could borrow an original manual and get it printed and bound for 4 to 6 times the cost, you could get better quality. In that case you wouldn't be here. For price, utility, and availability I am rating this manual highly.
;
I received the Manual in a timely manner and it was exactly what I needed.
This is a perfect copy of the Service Manual, The quality is great. I am very
happy. Thank you
;
exactly as they say. Within 24 hours the link to the pages and offcourse it was the right service manual. Super and thanks
After a data error is discovered, you will not be able to input or edit data. In order to return memory to normal (allowing further input and editing of data), you must perform the RESET operation to clear the memory of all data. Before doing so, you may want to recall important data and write it down (if you don't already have a copy). You can then re-input the data after clearing the memory. The RESET procedure you should use depends on the type of message error message on the display. "ARE YOU USING A NEW UNIT FOR THE FIRST TIME ?" 1. Make sure that NO is highlighted and then press set. If YES is highlighted, press to move the highlighting to NO and then press SET. � The message "DATA ERROR ! CHECK YOUR USER'S GUIDE FOR PROCEDURE !" appears on the display at this time.After this message appears, you can press CLEAR to clear it from the display and recall data in order to make a back-up record of it before continuing. 2. Press the RESET button, which is located inside the battery compartment cover on the back of the unit. � This causes the "CLEAR MEMORY AND SET UP THE UNIT FOR OPERATION ?" message to appear on the display. 3. Press to move the highlighting to YES and then press SET to reset the uint. � Highlighting NO and pressing SET clears the reset message and displays the Home Time screen. "CLEAR MEMORY AND SET UP THE UNIT FOR OPERATION ?" 1. Make sure that YES is highlighted. If OFF is highlighted, press to move the highlighting to YES. � Highlighting OFF and pressing SET turns off the unit without resetting the unit. 2. Press SET to reset the unit. If you still have trouble after trying the RESET operation, you may have a hardware problem.
�
lf a low battery power message appears on the display or if the display remains blank when you turn power on, replace batteries as soon as possible.
2. press OFF to switch power off.
About Auto Power Off function...
The SF Unit is equipped with an Auto Power Off function that switches power off automatically whenever you do not perform any key operation for about six minutes. To restore power, press ON.
To turn on the EL backlight
There are two ways to turn on the backlight of the display. Pressing LIGHT causes the backlight to turn on for about 15 seconds, and then turn off automatically. Pressing SHIFT and then LIGHT also turns on the backlight, but in this case the backlight stays on as long as you keep performing key operations on the SF Unit . The backlight turns off automatically if you do not perform any key operation for about 15 seconds. Leaving the backlight on for long periods greatly reduces battery life! You can manually turn the backlight off by pressing LIGHT again. Failure of the backlight to turn on indicates low battery power. Replace batteries as soon as possible.
�6�
|
|
|
> |
|
