To reset after viewing data 1. After the DATA ERROR message appears, press OK (Yes). 2. In response to the message that appers (DATA ERROR! CONSULT YOUR USER�S GUIDE FOR CORRECT PROCEDURE.), press OK. � This enters the CLOCK Mode. 3. Now you can enter other modes to recall data and make handwritten copies if you want. 4. After recalling tha data you want, perform the RESET operation under �To reset the BN Unit� on page 16. To reset immediately 1. After the DATA ERROR message appears, press ESC (No). 2. Continue from step 3 under �To reset the BN Unit� on page 16.
s Basic Settings
Use the following procedures to configure the hardware features of the BN Unit. To set the on-screen message language
1. Press MENU BAR to display the menu bar. 2. Use 3. Use to highlight SYSTEM, and then press and . to select the language you want to use.
to highlight LANGUAGE, and then press OK.
4. In the dialog box that appears, use
5. Press OK to register your setting and close the dialog box. � Pressing ESC in the above step closes the dialog box without changing anything.
To turn the key input tone on and off 1. Press MENU BAR to display the menu bar. 2. Use 3. Use � to highlight SYSTEM, and then press .
to highlight SOUND, and then press OK. to select KEY TONE. .
4. In the dialog box that appears, use
The selected setting is the one whose on or off setting appears as and to turn the key input tone on and off.
5. Use
6. Press OK to register your setting and close the dialog box. � Pressing ESC in the above step closes the dialog box without changing anything. � Turning on the key input tone causes the BN Unit to beep any time one of its keyboard keys is pressed. To adjust display contrast 1. Press MENU BAR to display the menu bar. 2. Use 3. Use to highlight SYSTEM, and then press .
to highlight CONTRAST, and then press OK. to make the screen lighter, and to make it darker.
4. In the dialog box that appears, press
5. After you are finished making the setting, press OK or ESC to close the dialog box.
� 10 �
|
|
|
> |
|
